Creek Audio - 4040a - Integrated Amplifier & DAC
Get ready to unlock an entirely new level of auditory experience with the groundbreaking Creek Audio - 4040a - Integrated Amplifier & DAC! As an epitome of audiological innovation, the 4040a rejuvenates the classic charm of our esteemed CAS4040 model from 1982, skillfully fusing nostalgic pleasure with state-of-the-art technology.
Key Features
- Intuitive User Interface and Sophisticated Menu System: The 4040a comes equipped with a user-friendly UI combined with an elaborate menu system, making the setup and usage a breeze.
- Three Analogue Signal Inputs: This includes two pairs of unbalanced RCA sockets and one pair of fully balanced XLR sockets, along with electronic volume and balance control that enables precise 1dB adjustment within a 70dB range.
- Optional Plug-in Sequel mk4 Phono Pre-amp: Designed to accommodate a wide range of Moving Magnet and high-output Moving Coil cartridges for vinyl music lovers.
- High Current, Dedicated Headphone Amplifier: Front panel-mounted jack socket, compatible with a wide range of headphones for direct audio enjoyment.
- Multiple Digital Inputs: With connectivity options like Coaxial SPDIF, optical TOSLINK, USB class 2 and aptX Bluetooth 5.0, most digital sources can be connected with ease.
- 32-bit ES9018K2M Sabre32 Reference DAC: Ensures seamless conversion of digital signals into high-quality analogue sound.
- MERUS™ Infineon Technology Power Amplifier: Developed to drive even the most taxing multi-driver loudspeakers with high fidelity.
- High-Frequency Power Supply: Exclusively optimized for audio electronics, this addon enables superior performance unaffected by mains quality or voltage stability.
- Standby Feature: Powers down non-essential circuitry during periods of no usage, which helps in power conservation.
Key Benefits
- Advanced Technology, Vintage Charm: Enjoy best of both worlds with the 4040a. Skillfully bridging the gap between nostalgia and modernity, this product delivers exquisite sound quality that was once only associated with vintage models.
- Top-Grade Precision: Remarkable volume and balance control capabilities provide a detailed and customizable audio experience.
- Versatile Compatibility: The 4040a is designed to cater to both vinyl music enthusiasts and digital audio fans with its extensive connectivity and compatibility features.
- Unparallel Sound Quality: With its dedicated headphone amplifier and Sabre32 Reference DAC, the 4040a guarantees high fidelity sound that will enthrall both casual listeners and audiophiles.
- Unflinching Power: Using MERUS™ Infineon technology, the integrated amplifier can effortlessly drive even the most demanding loudspeakers, making it suitable for any setup.
- Energy Efficient: The standby feature helps conserve power by shutting off unnecessary components and operations when not in use, making it environmentally friendly.
- Long-lasting Performance: With its high-frequency power supply particularly optimized for audio electronics, you'll enjoy top-tier performance graph even after extended periods of usage.
Specifications
Specification | Description |
---|---|
Product | Creek Audio - 4040a - Integrated Amplifier & DAC |
User Interface | Intuitive Interface with Rotary Control Knobs and Remote Control |
Pre-Amplifier | 3 analogue signal inputs (2 pairs RCA, 1 pair XLR) |
Volume Control | Electronic volume and balance control (1dB adjustment over a 70dB range) |
Tone Controls | Available |
Phono Pre-amplifier | Optional Plug-in Sequel mk4 Phono Pre-amp |
Headphone Amplifier | Dedicated High Current Amplifier |
Digital Inputs | Coaxial SPDIF, Optical TOSLINK, USB Class 2, aptX Bluetooth 5.0 |
DAC | 32-bit ES9018K2M Sabre32 reference DAC |
Power Amplifier | Implemented with MERUS™ Infineon Technology |
Power Supply | High-Frequency Power Supply, Optimised for Audio Electronics |
Power Output | 55 W into 8 Ohms, 110 W into 4 Ohms |
Continuous Max Output Current | >8A, current limited |
THD and Noise | <0.01% |
Signal to Noise Ratio | 102dBA |
Frequency Response | 1Hz to 50 kHz, +/-3dB |
Input Sensitivity | 440mV |
Crosstalk | >100dB at 1 kHz |
Loudspeaker Outputs | 4mm Binding Posts with Rear and Side Entry, Plus a Spade Lug |
Speaker Output Impedance | <0.02 Ohms 20Hz to 20 kHz |
Damping Factor | >400 into 8 Ohms |
Headphone Output Socket | 6.3mm Stereo Jack Socket for 30 – 300 Ohm Headphones |
Mains Input Voltage Range | 100V to 240V Nominal, 50Hz or 60Hz |
Fuse | Built into the power supply (not user serviceable) |
Power Consumption | 5W, 250W, <0.5W – Idle, Max, Standby |
Auto Standby | Adjustable Pre-set Time without Signal or Defeat In Menu |
Finish Colours | Optional Silver or Black Front Panel |
Weight | 2kgs (4.4 lbs) Net, 3kgs (6.6 lbs) Gross (Packed) |
Size | 21.5 x 6 x 25.5 cm (8.46″ x 2.36″ x 10”) Including Feet, Knobs, LS Terminals, and BT Antenna |
